l Product Description:
Extend Lines or Vacuum Bagging and Infusion
Spiral Tubing is a resin infusion standard and is ideally suited for in-bag vacuum line extenders or resin feed lines. This tubing is often used in vacuum infusion to allow vacuum pressure to be easily dispersed around a part. To ensure resin flow is not impeded, we recommend wrapping tubing in nylon or polyester peel ply.
Flexible vacuum infusion translucent plastic spiral tube for resin distribution of all types of thermosetting resins and for vacuum bagging processes.
Resin infusion hose -- It is made of PE and used to provide a very free‐lowing channel through which the resin is distributed near the point where the resin is first fed into the composite.
Spiral hose -- Resin flows freely through the center of the spiral tube, but just as easily out of the spirals in the side, allowing resin to be supplied all the way along an edge of the composite.
Customized logo(Min. order 10000 meters)
Customized packaging(Min. order 10000 meters)
Graphic customization(Min. order 10000 meters)
l Product Specifications
Product Code | Inner Diameter
(mm) | Outside Diameter
(mm) | Recommended TEMP ℃ | Material | Color | Packing Way |
SWφ12 | 9 | 12 | 80 | PE | Transparent | 50m/rolls |
SWφ12 | 9 | 12 | 120 | PP | Transparent | 50m/rolls |
SWφ14 | 11 | 14 | 80 | PE | Transparent | 50m/rolls |
SWφ14 | 11 | 14 | 120 | PP | Transparent | 50m/rolls |
SWφ16 | 13 | 16 | 80 | PE | Transparent | 50m/rolls |
SWφ16 | 13 | 16 | 120 | PP | Transparent | 50m/rolls |
l Product Features
*Low material cost.
*PE material, strong tube wall makes the spiral tube not deformed under atmospheric pressure.
l Packaging Information
PE bag or carton
l Storage Method
Stored in a cool and dry place, and make sure not directly touch the ground or wall to avoid moisture. Do not remove the original packaging when store.
l Scenes To Be Used:
Used in vacuum infusion and prepreg process.
